Making Education a Fun Activity

INTRODUCING NEXT LEVEL OF INTERACTION WITH AXEON WALL-E

YOUR BUSINESS - OUR TOOL - OVERALL SUCCESS

Learning made easy and interactive

Experience a new way of Learning

UNMATCHED   PICTURE

   QUALITY

BUILT-IN

      PC

   AFFLUENT

      AUDIO

10 POINT

 TOUCH

INTEGRATED   SOFTWARE

Technical Specs
Connectivity

Infrared Rx Sensor

 Yes

USB Ports

                     4

USB 2.0 configuration

                    0+1

USB 3.0 configuration

               2B 2F + 0

SATA 6.0 Gb/s ports

                          2

Integrated LAN

      10/100/1000

Integrated Wifi

       Wireless-AC 7265+BT 4.2

Additional Headers

              2xUSB2.0, AUX_PWR

Integrated PC System
Panel Specifications

  Panel Type

               TFT/LCD

  Aspect Ratio

                        16:9

  Integrated Speaker

    10Wx2

  Touch Type

             Multi-point touch(6-10 point)

  Interpolation resolution

                     32767×32767

  Response

                    ≤15ms

  Touch Accuracy

                over 90% area(±2mm)

  Input form

     Finger, glove hand or Opaque object

  Output form

        Coordinate output

  Transmission speed

       12Mbps

  Supply voltage

   DC+5v±5ï¼…

Single push-button power

               Yes

Power System

Custom lockable enclosure

        Yes

      Universal 110-240V

Operating System

      Windows10/Android(latest)

Storage Condition

Operating Temperature

        -10℃~50℃

Storage Temperature

     -20℃~60℃

Operating Humidity

           10%~85% RH

Storage Humidity

    10%~90% RH

Warranty

1 Year limited Warranty + 3 Year extended Warranty

1 Year replacement Warranty on Accessories

  Working current

       <300mA

  Protactive Glass

      4mm tempered(anti-scratch)

Standard

  CPU

    Intel i3-5010U

  Processor Speed

       2.1 GHz

  Processor Count

                 2

  Storage

    128GB SSD(Expandable)

  Memory

           4GB RAM(Expandable)

  Graphics Coprocessor

       Intel HD Graphics 5500

Accessories

AC Power Supply, Quick Start Guide, Writing Pens,

Remote Control, HDMI Cable, Audio Cable, USB Cable
